1.Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.
2.Computer PLC control and automatic alarming function.
3. English and Chinese human-machine operation interface, it is easy to operate, a high degree of automation.
4.High sensitivity photoelectric eye color tracing, more accuracy.
5. Famous brand components, ensure the quality and durability of the machine.
| Measurement Range | 50~200ml |
| Packing Size | L: 40-200mm W: 50-150mm |
| Packaging Speed | 30~80bags/min |
| Machine Size | (L)1100*(W)755*(H)1540mm |
| Machine Weight | 300KG |
Sealing Style | Three/Four sealing /Back sealing |
| Cutting | Tooth Cut / Flat Cut |
| Power | 220V,50HZ,1.2KVA |
1st 1st step: Setting the parameters you want by touch screen
2nd step: Put the material into the stainless steel hopper
3rd step: The measurement parts will measure the weight of each bag automatically
4th step: The bag former will make the bag automatically
5th step: The horizontal and vertical cutter device will seal the middle and of the bag.
6th step: You will get the nicely paper or plastic bag type
Electrical configuration
These are the electrical configurations on the packaging machine, from different brands and different countries.
