Full automatic stick package coconut milk powder packing machine

Machine Model: JS-320C

Price:3500-4100$

Automaticity: Full Automatic

Packaging Bag Size:(W)30~150mm (L)40~200mm

Film Width: Max.320mm

Packing Speed:30~70bag/min

Material: SUS304

Machine Size: (L)1100*(W)750*(H)1580mm

Machine Weight: 350KG


Share:
  • Product Introduction
  • Product Parameters
  • Contact Us
Feature

1. The machine is suitable for food products of particles, powder, liquid, paste and another measurement packing.

2. All the works of bag making, measuring, filling, sealing, cutting and counting can be done automatically, at the same time, it can also according to the demand of customers to add printer and other options.

3. The touch screen operation, PLC control, drives stepper motor to control the bag length, stable performance, easy to adjust and accurate detection.

4. Packing material: BOPP/Polyethylene, Aluminum/Polyethylene, Paper/Polyethylene, Polyester/Plated Aluminum/Polyethylene, Nylon/CPP and so on.


Application

All Kind Of Powder product: milk powder, coffee powder, tea powder, soybean powder, flour, protein powder, spice powder, etc.

Full automatic small sachet coffee powder juice powder packing machine

Automatic hot chocolate powder stick packing machine

Samples

Automatic stick bag matcha tea powder ice tea powder drink powder packing machine

Specification

Automatic hot chocolate powder stick packing machine

  1. Turn on the packing machine, set the packing parameter on the touch screen and wait the sealing temperature to set value.

  2. Put packing material to hopper.

Vertical automatic pouch packing chili powder curry powder machine price

3. Put the packaging film to packing film holder and the bag former, switch on the machine, and test machine working status.

4. Powder material will measuring by screw measuring part, auto bagging.

Vertical automatic pouch packing chili powder curry powder machine price

5. Bag former automatic bag making, vertical sealing device auto bag sealing.

6. Finished product will cut out by cutting device; you will get a beautiful product.

Automatic hot chocolate powder stick packing machine

Full automatic stick package coconut milk powder packing machine

Combined Parts
None
Request a quote
ModelJS-320C
Bag length40~200mm
Bag width50~150mm
Film width320mm
Measuring range20-200ml
Packing speed30~80bag/min
power220V,1.2kva,50/60HZ
Machine size1100*750*1580mm
Sealing type3/4 side seal, back seal
Machine weight350kg
